PRNT 15.5KV，Oil-Immersed Transformer Bay-O-Net Fuse manufacturer，use for Overload Protection，Professional Bay-O-Net Assembly supplier

LATU，Professional bay-O-Net Assembly supplier，PRNT 15.5 manufacturer，own factory specialized in producing it，copper/brass Fittings+FRP tube.

Bay-O-Net Fuse for Overload Protection of Oil-Immersed Transformer

The Bay-O-Net Assembly is the brief element of oil-transformer, to protect the equipment when over-current. When install the fuse wire in it, the Bay-O-Net will provide the safe, highly efficient protection, according to the current, oil-temperature.

High-voltage fuse for overload protection of oil-immersed transformerThis product applies to indoor AC 50~60Hz system with the rated voltage of 15.5kV and shall be used in series with the backup fuse for oil-immersed transformer overload protection, and can provide the full range protection for indoor power system. The product has passed the type test conducted by the national high-voltage electrical equipment quality supervision and inspection center, and conforms to GB15166.2 and IEC282-2.

Model:



Basic parameters:



Product Model

 (kV)

 (kV)

 (A)

PRNT-15.5

60,100,140

The Bay-O-Net Assembly is suitable for current sensing fuse wire, dual sensing fuse wire, dual element fuse wire, and ELSP current-limiting backup fuse, etc.

It is suitable for high-voltage power system with alternating current of 50Hz, standard voltage of 15.5kV, current rating of 140A. It must be combining with MagnX Interrupter of ELSP Current-Limiting Backup Fuse to protect transformer from overload and short circuit.

23kv and 38kv sidewall mounted and 23kv cover mounted bay-o-net fuse for pad mounted transformer

LATU protects transformer and distribution systems with Bay-O-Net fuse assemblies, They are designed for use in pad-mounted transformers filled with fluid, transformer oil or approved equivalent. The assemblies combine the ease of hotstick operation with the safty of deadfront construction.

Silver-plated Flapper valve Bay-O-Net assemblies are available and recommended for use with the high ampere overload links.

Installation

No special tools are required. The fuse assembly is mounted through the transformer tank wall for sidewall-mount and through the tank cover for cover-mount. The incoming high-voltage lead is connected to the isolation link or current-limiting fuse. The isolation limk or current-limiting fuse is connected to the lower contact of the fuse assembly. and the upper contact is connected to the transformer winding.
